Shipping Sage: a paid AI agent settled on Ergo testnet

Sage is a single-site agent-economy concierge:

• Free tier - Claude Haiku over an indexed corpus of Ergo docs and blog posts. Short answers, conservative refusal behavior, rate-limited per IP.
• Premium tier - Claude Sonnet with deeper retrieval, larger answer budget, and a payment gate. One premium turn costs 0.001 testnet ERG.
• Receipts - paid turns resolve to public Sage receipt pages. The first full redemption also appears in Sage's live activity feed and the Ergo testnet explorer.

The premium gate is intentionally conservative. It triggers on explicit /command prefixes, code-request hints, deep-research phrasing, very long questions, or multi-turn follow-ups in a long thread. The heuristic lives in src/lib/sage/payments/gate.ts. We bias toward false negatives: under-charge early users rather than surprise them.

Sage is not a custom one-off payment widget. It uses the same vocabulary the Accord Protocol defines:

That last nuance matters. The architecture is designed for stronger script-level enforcement, and the SDK supports compiled script paths, but the current public Sage proof should be described precisely: testnet Note verification plus real on-chain redemption, not audited mainnet custody and not a completed mainnet-ready spending-condition audit.

1.  User asks a premium-shaped question.
2.  Widget POST /api/sage/chat -> server returns a payment-required response.
3.  Widget POST /api/sage/quote -> server returns SageQuote:
      receiver_address  3Wz1Lmu...AY28w
      reserve_box_id    4af1816c...628a4d
      task_hash         blake2b256(canonicalized question)
      price             0.001 testnet ERG
      deadline          +120 blocks
      expires_at        quote freshness deadline
4.  Payment panel renders the quote with copy buttons and instructions.
5.  Buyer issues a Note with R4=reserve, R5=expiry, R6=task_hash.
6.  Note tx confirms on Ergo testnet.
7.  Buyer pastes note_box_id into the panel and clicks Verify.
8.  Server POST /api/sage/verify-payment:
      - rails-ergo fetches the Note from chain
      - checks R4 reserve binding
      - checks R5 expiry
      - checks R6 task hash
      - checks value >= price
9.  Server returns a payment token and receipt reference.
10. Widget resumes the chat with paymentToken.
11. /api/sage/chat routes to the premium model path.
12. Premium answer streams back to the user.
13. If the signer is available, Sage redeems the Note.
14. The settlement tx becomes visible on Ergo testnet and on /r/sage/<id>.

The first confirmed full redemption landed at Ergo testnet block 345673.

The first Sage version shipped in verify-only mode.

That meant Sage verified the buyer's Note and delivered the premium response, but deferred the final seller redemption transaction. This was deliberate. Putting a seller wallet private key directly into a serverless environment is poor operational hygiene: compromise of an LLM API key should not imply compromise of the payment wallet.

The signer is now wired for the live testnet flow.

That moves Sage from "verified, settlement pending" to "settled on Ergo testnet" for the first proof transaction. The public activity feed now reports a settlement event, and the receipt page for the settlement tx returns HTTP 200.

The current public proof shows that:

• Sage can detect a premium request.
• Sage can price it as an Ergo testnet Note.
• A buyer can issue the Note.
• Sage can verify the Note against the quote.
• Sage can serve the premium answer after verification.
• Sage can redeem a Note on Ergo testnet.
• The settlement transaction is externally visible.
• Other agents, dashboards, or conformance tools can poll the activity feed instead of trusting a screenshot.

That is a real milestone.

This does not certify mainnet use.

It also does not make the Sage pilot a full Accord protocol pass yet.

The remaining piece is conformance evidence. The storage path for full receipt bundles is now implemented, but a protocol pass needs one new paid Sage turn after the Blob deployment, then an external conformance run against the stored bundle.

The honest status is:

On-chain Sage settlement is proven. Full receipt storage is live for new receipts. Signed conformance evidence is still pending.

That distinction is important. Old chain-only receipts cannot be magically upgraded because the original Agreement and signed verification receipt were not stored at the time. New receipts can carry the full bundle.

The Sage payment path lives in a small set of files:

src/lib/sage/
├── retrieve.ts                 Retrieval over the doc index
├── rate-limit.ts               Per-IP sliding window
├── payments/
│   ├── agreement.ts            buildSageQuote() + canonicalizeQuestion()
│   ├── gate.ts                 decidePremium() heuristics
│   ├── note-ops.ts             Explorer response normalization for rails-ergo
│   ├── token.ts                HMAC payment token, bound to question hash
│   ├── verify.ts               rails-ergo verifyPayment + settle
│   ├── wallet.ts               signer URL, local seed, or verify-only fallback
│   └── types.ts                SageQuote, PaymentProof, result types
└── explorer/
    └── fetch-tx.ts             Testnet explorer fetcher and activity shaping

src/app/api/sage/
├── activity/route.ts           Public Sage chain activity feed
├── accord/route.ts             Accord/402 conformance bridge
├── chat/route.ts               SSE streaming endpoint, premium-aware
├── quote/route.ts              POST { question } -> SageQuote
├── receipt/[id]/route.ts       Public machine-readable receipt source of truth
└── verify-payment/route.ts     POST { quote, question, noteBoxId } -> token

src/app/[locale]/r/sage/[id]/
└── page.tsx                    Public receipt page

scripts/sage-signer/
├── bootstrap.mjs               Reserve and self-test helper
└── signer.mjs                  Standalone HTTP signer

The bulk of the complexity is not the chat UI. It is the payment boundary: canonicalizing the task, preserving the exact bytes being hashed, normalizing explorer data, and keeping the signing key outside the website runtime.

1. Explorer Box Lookups Needed Fallbacks

Sage's verification path depends on reading a fresh Note box from Ergo testnet. In practice, the explorer shape was not as clean as a single happy-path endpoint. The code now wraps and normalizes the explorer response so the rail adapter sees the box shape it expects.

2. Registers Arrived As Objects, Not Plain Hex

The v1 testnet explorer can return additionalRegisters as objects like:

{ serializedValue, sigmaType, renderedValue }

Some SDK paths expected plain serialized hex strings. Without normalization, register parsing fails before the rail can inspect R4/R5/R6. src/lib/sage/payments/note-ops.ts flattens those registers before handing them to the Accord Ergo rail.

3. Task Hashes Must Name The Exact Bytes

rails-ergo computes blake2b256(task_output) and compares it to the Note's R6.

That means task_output must be the exact canonicalized question bytes the Note committed to. A session-token hash, payment-token hash, or HMAC binding hash is not interchangeable.

This was the biggest implementation lesson: when two layers use hashes, variable names must say what is being hashed.

Sage is a live testnet demonstration.

The correct posture is still conservative:

• testnet only;
• no mainnet certification;
• no external audit claim;
• old pre-storage receipts may remain chain-proof-only;
• no claim of Accord conformance until the signed artifact is published;
• no claim that every future deployment is safe by copying this one;
• external audit and mainnet manifests still pending.

That is not weakness. It is the difference between a credible build log and marketing.

The next step is not "prove settlement" or "add storage." Those parts have happened.

The next step is to turn the implementation into evidence:

• create one new paid Sage turn now that Blob storage is live;
• confirm /api/sage/receipt/<id> returns completeness: "full_receipt_bundle";
• run the Accord conformance runner against /api/sage/accord;
• sign the conformance artifact;
• publish the artifact URI in the Accord registry evidence.

After that, Sage can move from "settlement proven and storage-ready" to a protocol-level pass.

Then come the bigger roadmap items:

• surface the Accord provider registry on the site;
• show live agent activity in more places;
• expand the published @ergoblockchain/sage-widget v0.1.0 package from activity-feed components into a fuller reusable Sage embed;
• move the public MCP endpoint from the live Fly URL to mcp.ergoblockchain.org once DNS is live;
• run external audits before any mainnet claims;
• sign exact script/contract manifests before any controlled mainnet launch.

Open ergoblockchain.org. Bottom-right, click Ask Sage.

Free questions stay free. Premium-shaped questions trigger the testnet payment panel. Use testnet funds only.

The useful point is simple: this is no longer just a page about agent payments. It is a working testnet agent payment path with a real on-chain settlement trail.
